Lan speed |
10/100 Mbps |
Dimensions |
87 × 44 × 29.2 mm |
Weight |
92 g |
Output voltage |
24VDC @ 0.5A |
LAN activity indicator |
No |
Gigabit LAN port |
No |
Remote resetting capability |
Yes |
Reset button |
Yes |
Input voltage |
90-260VAC @ 47-63 Hz |
Input current |
0.3A @ 120VAC, 0.2A @ 240VAC |
Inrush current |
<30A Peak @120VAC, <60A Peak @ 230VAC |
Effectiveness |
75+% |
Output current pulsation |
1% Max. |
Switching frequency |
50 kHz |
Linear adjustment |
± 1% |
Load adjustment |
± 3% |
2 steam power supply |
Pins 4, 5 (+) and Pins 7, 8 (-) |
Operating temperature |
0 to 40° C |
Storage temperature |
-30 to 70°C |
Humidity during operation |
35 to 95% |
AC connector |
IEC-320 C6 |
Date IN / POE |
RJ45 , shielded socket |
Surge protection |
Modes: Difference and Common |
Clamp protections |
11 V Data, 60 V Power |
Highest pulse rate |
36A (10/1000µS) Date |
Electric capacity of the shunt |
<5 pf date |
Response time |
<1 nS |
Compatibility |
IEC 60950-1:2005+A1 UL60950-1EN55022:2010, EN55024:2010 FCC Class B |
AC cable |
Not Included |
