High-Performance Next-Generation Firewall
The RG-WALL 1600-Z3200-S is a high-throughput, next-generation firewall designed for large-scale enterprises, data centers, and campus networks requiring advanced security without sacrificing performance. It delivers full-layer protection, intelligent traffic analysis, and integrated threat detection with superior reliability.
This device supports a wide range of security functions including IPS, application control, anti-virus, URL filtering, VPN, and behavior-based detection. With flexible deployment options and high availability support, it is optimized for complex and high-demand environments.
Licensing Information
Ruijie makes deployment simple and cost-effective with a 1-year free security license included:
- Bundled License: Comes with Five-in-one RG-WALL 1600-Z3200-S-LIS-E-1Y, valid for 1 year
- This license activates key NGFW security features:
- Intrusion Prevention System (IPS)
- Application Identification & Control
- Antivirus
- URL Filtering
- Threat Intelligence updates
- All core functions — including firewall, NAT, routing, and VPN — work without any license
- After 1 year, license renewal is optional and modular based on required features
The included 1-year license enhances protection without adding cost at the start.
Technical Specification:
| Firewall Throughput | 10 Gbps |
| Concurrent Sessions | 8 million |
| New Sessions per Second (NSS) | 180,000 |
| Firewall Traffic Mix | 3 Gbps |
| Threat Protection | 1 Gbps |
| Application Recognition | 2,600+ applications |
| Threat Protection | IPS, antivirus, anti-DDoS, URL filtering, botnet protection |
| Deployment Modes | NAT, Transparent (Bridge), Routing, Hybrid |
| VPN Support | IPSec, SSL VPN, L2TP, GRE, MPLS VPN |
| Virtual Firewalls (VDOMs) | Supported |
| Interfaces | Modular; supports GE/10GE/40GE interfaces |
| High Availability (HA) | Active-Active and Active-Standby with session sync |
| Management | Web UI, CLI, SNMP, Ruijie Cloud, RG-Cloud AC |
| Logging & Reporting | Built-in log management, syslog export, flow analysis |
| Routing Protocols | Static, RIP, OSPF, BGP, PBR |
| Power Supply | Dual hot-swappable AC power supplies |
| Dimensions (W × D × H) | 430mm × 600mm × 88.1mm (2U Rackmount) |
| Weight | Approx. 12.5 kg |
| Operating Temperature | 0°C to 45°C |
Key Features
- Deep Packet Inspection (DPI) and full application-layer traffic control
- Integrated threat intelligence and real-time security updates
- Multi-tenancy support with virtual firewalls (VDOMs)
- Scalable modular interface design for flexible networking requirements
- Comprehensive VPN gateway capabilities with encryption acceleration
- Cloud-managed or standalone operation, ideal for hybrid environments
