Reyee Wireless Bridge Kit - Pre-Paired - 2.4GHz 500m Range

66.40
(81.67 inc VAT)
RG-EST100-E
In stock
+
Reyee Wireless Bridge Kit - Pre-Paired - 2.4GHz 500m Range

Features:

  • RG-EST100-E can easily transmit data from 500m away in real time
  • Factory-free configuration, without complex alignment
  • IP55 Weatherproof, -30℃~60℃ guarantee stable operating at outdoor or elevator environment
  • Supports a maximum of 10 * 3MP cameras loading at 100m, 5 * 3MP cameras loading at 500m
  • Visually Intuitive statistics monitoring on Ruijie cloud, easy remote maintenance
  • Perfect for CCTV in elevators

Key Specification

Radio Design: 2.4 GHz Single-Band Dual-Stream
Operating Band: 802.11b/g/n: 2.400~2.483GHz
Polarization: Horizontal: 70°, Vertical: 70°
Spatial Streams: 2x2, MU-MIMO
Maximum Throughput: Up to 300 Mbps at 2.4 GHz
IP Rating: IP55
Installation: Wall-mounted/ Pole-mounted
Weight: 0.3 kg
Transmission Protocol: IEEE 802.11b/g/n
Antenna: Directional antennas, 8 dBi
Bridging Distance: 500m (recommended)
Memory/Flash: 64 MB/8 MB
Max. Transmit Power: ≤100 mW(20 dBm) (adjustable)
Lightning Protection: ±6 KV(Common Mode)
Dimensions (D x W x H): 165.5mm×68.7mm×42mm



Datasheet (RG-EST100-E_2.4GHz_Dual-stream_500m_Wireless_Bridge-20230712.pdf, 1,597 Kb) [Download]
