Netvio 4x4 HDBaseT Matrix Switch | 4K@60Hz, ARC, HDMI Mirroring, 16x8 Audio Matrix, Netvio GO App
.png)
Not all 4K is the same
With Netvio, you get professional-grade 4K60 video quality that surpasses the competition. Perfect for any project demanding excellent image resolution and color accuracy. Unlike older lower cost alternatives with limited capability, our dedicated ethernet cabling ensures maximum compatibility and performance every time!
Multi Room Audio Matrix
The MX-HT2-0404 is a great way to increase your profits by removing an external audio matrix but maintaining functionality. It has all the audio switching capabilities you would expect with out the additional cost!
.png)
Awesome Output 4!
Tackle even the toughest installations with ease. With our MX-HT2-0404, you can get 70 meters of high-quality cable output to ensure nothing is lost in transmission—plus network extension capabilities for added convenience. Don't let unpredictable assignments stand between success and failure - take control with powerful output 4!
4 Source Audio Pre-Amp
Unlock increased profitability with the MX-HT2-0404! This highly advanced audio matrix with 4no audio pre-amp inputs offers all desired audio switching capabilities, allowing you to take full advantage of its features without adding to your costs.
.png)
Capture & Distribute
Installers no longer have to worry about the hassle of capturing and routing audio from display sources with the MX-HT2 0404 10. This innovative technology simplifies the process, allowing you to quickly capture any ARC audio content streaming form your screen apps through a multi-room amplifier effortlessly! Get all the details here now!
.png)
HDMI Mirror, Mirror ......
Netvio's MX-HT2-0404-10 is a revolutionary way to expand your viewing experience. This device allows you to add additional devices without any extra cost through its pure HDMI mirror outputs, perfect for connecting AVRs and bringing out the best of Netvio's product line.
4K to 1080p Scaling
Our MX-HT2-0404-10 provides an awesome viewing experience for your customers, with smart scaling technology that eliminates the need for unsightly conversion boxes. By seamlessly converting 4K content to 1080p display capability you can rest assured that everyone will be able to enjoy a top quality picture on whatever device they use!
10-Year Warranty Option
The 5 year standard warranty is an industry best, but that doesn't mean you should stop there. For 10%, more protection can be extended to a total of ten years with our additional long-term SafeGuard service agreement.
Specifications
VIDEO
- Encoding Data Rate
- HDMI: Max 17.82Gbs
- HDBaseT: Max 10.2Gbs subject to variable stream compression and up-conversion.
- Max Video Transmission
- 3840x2160 60fps 4:4:4 8b
- HDBaseT
- Outputs 1-3 | HDBaseT (10.2Gb) @ 40m 4K/60 HDR | 70m/1080p.
- Output 4 | HDBaseT (10.2Gb) @ 70m 4K/60 HDR | 100m/1080p.
- HDMI (Inputs/Outputs)
- Supporting HDMI 2.0b resolutions including 3840x2160 60fps HDR.
- Max Pixel Clock
- 600MHz / 600Mcsc
- HDR Compatibility
- HDR10, HDR10+, Hybrid Log-Gamma, Dolby Vision
- Scaler Function
- 4K to 1920x1080 progressive
- Modes include, pass-through (no scaling), Fixed 4K → 2K, Automatic
- HDCP
- Inclusive up to 2.2
AUDIO
- Audio Formats:
- LPCM 2ch, LPCM 5.1, LPCM 7.1, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS Master
- Audio Outputs:
- 4no. 2ch variable line level stereo analog audio Jack socket
- 4no. S/PDIF audio via female RCA socket, S/PDIF digital audio supporting uncompressed PCM and non-linear PCM-encoded bitstreams.
- Audio Return Channel:
- ARC capture from compatible display, matrix & receiver (RX-HT2-40-20 | RX-HT2-70-10)
- Audio Only Inputs:
- 2no. 2ch Stereo analog line audio inputs via jack socket
- 1no. S/PDIF (supporting LPCM and proprietary bitstreams) audio via female RCA socket,
- 1no. S/PDIF (supporting LPCM and proprietary bitstreams) audio via female optical TOSLink socket
- 16x8 Audio Matrix
- Inputs:
- HDMI Source de-embed 1-4
- HDMI ARC Zone 1-4
- HDBaseT ARC Zone 1-4
- Audio In 1, 2, 3, 4
- Outputs:
- No.4 | Mirrored HDMI outputs
- No. 4 | HDBaseT outputs
- No. 4 | Stereo + S/PDIF
COMMUNICATION & CONTROL
- HDMI:
- CEC, DDC
- HDBaseT:
- Supports CEC, DDC, Ethernet, RS-232 TXD, RXD and Infrared
- RS-232:
- Supports direct & routed RS-232 control, via a DB9 socket on the rear panel.
- Zone RS-232 Serial interface (3-pin) via Phoenix-style, 3.5mm pitch male receptacle.
- LAN:
- 1x IEEE 802.3u 100Base-TX Ethernet interface via “RJ45” socket.
- Local discovery and API console via Netvio 360 & Netvio Go APP,
- 3rd-party integration via public API
- Drivers & Control
- Drivers available for control systems including C4, Crestron, RTi & Elan.
- Discovery, configure, optimise, design via Netvio 360 utility.
- Full spectrum AV control via FREE Netvio application for Apple & Android devices.
- EDID
- Automatic, Onboard pre-sets, Copy sync (RX)
ENVIRONMENTAL
- Storage
- 20°C / +60°C | 20% - 90% RH
- Operating
- 0°C / +40°C | 20% - 90% RH
OTHER INFORMATION
- Power Supply:
- Internal PSU. supporting worldwide AC voltages (e.g. 120V/60 USA, 230V/50 UK)
- FREE Software & Control
- Netvio 360 utility - discovery, configure, optimise, design, control
- Netvio GO - Full spectrum AV control
- Weights & Dimensions:
- Rack Units: 2RU
- Height: 88mm
- Width: 440mm
- Depth: 373mm
- Weight: 6.9kg
- In the Box:
- Rack Ears
- IR Accessories
- Phoenix Connectors
- Remote Control
- Regionalised Power Lead
- Regulations
- Safety Approvals: CE, UKCA, FCC, RoSH
- Warranty
- 5-Year standard warranty (no registration required)
- 10-Years for 10% price increment
Note: RX Units sold seperately
