Specifications |
Model |
CS-CH1-A0-10AWFK |
Audio |
Ringtone |
Supports up to 20 options with adjustable volume |
Audio Output |
Built-in high-power speaker (Up to 72 dB in 1 meter) |
Network |
Protocol |
EZVIZ Cloud Proprietary Protocol |
Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
Supports 20 MHz |
Security |
64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
Transmission Rate |
11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
Antennas |
Dual external antennas |
General |
Operation Conditions |
-10°C to 45°C (14°F to 113°F) , humidity 95% or less (non-condensing) |
Dimensions |
101 × 64 × 32 mm (3.98 × 2.52 × 1.26 inch) |
Package Dimensions |
113 × 85 × 95 mm (4.45 × 3.35 × 3.74 inch) |
Power Consumption |
Max. 5W |
Power Supply |
AC 100 ~ 240V |
Net Weight |
87 g (3.07 oz) |
Weight with Package |
178 g (6.28 oz) |
Reset button |
Yes |
In the box |
In the box |
- CH1 Chime |
- Quick Start Guide |
- Regulatory Information |
Certifications |
Certifications |
UL / FCC / CE / WEEE / REACH / RoHS |
