Model Parameters |
Model |
CS-CMT-CHIME |
Network |
Protocol |
EZVIZ cloud proprietary protocol |
Interface Protocol |
EZVIZ cloud proprietary protocol |
Interface |
Storage |
No |
Wired Network |
Does not support |
Power Supply Interface |
EU/US/UK Standard Plug |
Wi-Fi |
Wi-Fi Standard |
IEEE802.11b / g / n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
Supports 20 MHz |
Security |
64/128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
Transmission Rate |
11b: 11Mbps, 11g: 54Mbps, 11n: 144Mbps |
Antennas |
Dual External Antennas |
General |
Operating Conditions |
Temperature: -10°C to 40°C (14°F to 104 °F ), Humidity: 95% or less (non-condensing) |
Power Supply |
100V - 240V AC |
Power Consumption |
Max 0.6W |
Dimension |
100 × 55 × 35 mm (3.94 × 2.17 × 1.38 inch) |
Weight |
120 g (4.23 oz) |
In the box: |
In the box: |
Chime; Quick Start Guide |
Certifications: |
Certifications: |
UL / FCC / CE / WEEE / REACH / RoHS |
