Save 27%

Cyberpower VP700EILCD Desktop 6 x IEC UPS 700VA/390W

List price: €155.00
€113.00
(€138.99 inc VAT) You save: €42.00 (27%)
VP700EILCD
In stock
+ −

Cyberpower VP700EILCD Desktop 6 x IEC UPS 700VA/390W

CyberPower VP700EILCD offers home and office users a reliable battery backup and safeguards office PCs and other electronic devices from surges, spikes, brownouts and other power incidents. Designed with GreenPower UPS™ Technology to improve UPS operating efficiency and to minimize its energy consumption, users can enjoy significant energy cost savings over conventional UPS systems. The UPS provides Automatic Voltage Regulation (AVR) to maintain safe voltage for connected equipment. The UPS provides multifunctional LCD readout to display clear power and battery conditions. The product features data line protection with high-speed transmission to safeguard phones, network and communication equipment against surge/spike as well as supply 1Gbps speed to transmit data. The UPS is also compatible with PowerPanel Power Management Software to achieve real-time monitoring and configuration.

  • Line-interactive UPS Topology
  • Generator Compatible
  • Automatic Voltage Regulation (AVR)
  • High-speed Ethernet Data Transmission
  • Surge and Spike Protection
  • PowerPanel Management Software
  • Energy Saving Technology
  • Simulated Sine Wave Output
  • LCD Status Display
  • USB Connectivity Port
  • Serial Connectivity Port

General

Phase
Single Phase
Form Factor
Tower
UPS Topology
Line-interactive
Energy Saving Technology
GreenPower UPS™ Bypass Technology

Input

Generator Compatibility
Yes
Nominal Input Voltage ( Vac )
230 ± 10%
Input Voltage Range ( Vac )
167 ~ 295
Input Frequency ( Hz )
50 ± 5
60 ± 5
Input Frequency Detection
Auto-sensing
Rated Input Current ( A )
3.04
Input Connector Type
IEC C14 　

Output

Capacity (VA)
700
Capacity (Watts)
390
On Battery Waveform
Simulated Sine Wave
On Battery Voltage(s) ( Vac )
230 ± 10 %
On Battery Frequency ( Hz )
50 ± 1%
60 ± 1%
Automatic Voltage Regulation (AVR)
Single Boost, Single Buck
Overload Protection
Circuit Breaker
Outlet(s) - Total
6
Outlet Type
IEC C13 x 6 　
Outlet(s) - Battery & Surge Protected
6
Typical Transfer Time ( ms )
4

Battery

Runtime at Half Load ( min )
10
Runtime at Full Load ( min )
1
Typical Recharge Time ( Hours )
8
Start On Battery
Yes
User-replaceable
Yes - Qualified Personnel Only
Battery Type
Sealed Lead-acid

Surge Protection & Filtering

Surge Suppression ( Joules )
450
EMI/RFI Filtration
Yes
Phone/Network Protection RJ11/RJ45 (Combo)
1-in, 1-out

Management & Communications

LCD Panel
Yes
LCD Information Display
Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information
LCD Setting & Control
Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning
LED Indicators
Power On
HID Compliant USB Port(s)
1
Audible Alarms
Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs )
Power Cord x1, USB Cable x1
Ethernet Data Transmission Speed
Up to 1Gbps
Power Management Software
PowerPanel Personal (Recommended)

Physical

Enclosure Construction
Plastic
Color
Black

Physical Size - UPS Module

Dimensions (WxHxD) (in.)
3.9 x 8.9 x 10.2
Dimensions (WxHxD) (mm.)
100 x 227 x 260
Weight (lbs.)
11.33
Weight (kg.)
5.14

Shipping Dimensions

Dimensions (WxHxD) (in.)
11.81 x 13.19 x 5.63
Dimensions (WxHxD) (mm.)
300* x 335 x 143
Weight (lbs.)
12.7
Weight (kg.)
5.76

Environmental

Operating Temperature (°C)
0 ~ 40
Operating Relative Humidity (Non-condensing) ( % )
0 ~ 90
Operating Elevation ( feet/meters )
0-9,843 feet (0-3,000 meters)
Storage Temperature (°F)
-4 ~ 122
Storage Temperature (°C)
-20 ~ 50
Storage Relative Humidity (Non-condensing) ( % )
0 ~ 90
Storage Elevation ( feet/meters )
0-9,843 feet (0-3,000 meters)
Online Thermal Dissipation ( BTU/hr )
9.5
Audible Noise at 1.0M from Surface of Unit ( dBA )
40

Certifications

Certifications
CE, EAC
RoHS
Yes

WARRANTY

Product Warranty Period (Year)
2
Battery Warranty Period (Year)
2


Datasheet (CyberPower_DS_VP700-1600E_I_LCD_en_v4.pdf, 6,426 Kb) [Download]
